This high quality, brand new remote display / monitor can be used with Photonic Universe IPT series high ferquency inverters. It's ideal for remote system monitoring as it allows you to have load power control via On/Off switch and power saving mode settings. This unit can display various parameters such as battery voltage, load voltage, load current, load power, and load frequency. The LCD display also includes an indicator for load status (on/off).

By adding this remote meter to your IPT series inverter, you will unlock exclusive settings to configure the power saving mode which gives greater control over your load settings. Set adjustable power thresholds to reduce consumption of the inverter automatically based on the load output. When operating in power saver mode the inverter output is turned on for 1 second and turned off 5 seconds to conserve power. When the load output is higher than the adjustable threshold it will resume normal continous output operation. This feature provides greater control to manage your power drain without having to manually turn off the inverter.

Additional Features:

Remotely control of the load output (on/off) for the inverter by holding the load switch for 2 seconds. Ideal for conveniently disconnecting the inverter from to reduce battery discharge when no load is required.

This remote meter also has self-diagnostic capability, and will highlight any system errors using advanced fault-targeting technology. Fitted with a fault LED indicator and buzzer to alert to issues with the inverter operation. The display includes error codes to diagnose the fault for convenient troubleshooting.

Accessible parameters:

- Output voltage: 220VAC / 230VAC / 240VAC
- Output frequency: 50Hz / 60Hz
- LCD backlight time: 30s / 60s / 100s
- Power saver mode & thresholds
- Baud Rate: 9600 / 115200
- Low voltage disconnect:  10.5V - 14.2V
- Low voltage reconnect: 11.5V - 15.2V
- Over voltage disconnect: 12.5V - 16.2V
- Over voltage reconnect: 11.5V - 15.2V

Compatibility:

This remote meter can be used with any of our high frequency IPT series inverters, e.g.:

- IPT-1000
- IPT-2000
- IPT-3000

The remote meter has a remote terminal to enable connection to a Wi-Fi module or Bluetooth module to further access the information of the inverter remotely. The connection will require an RS485 to RJ45 port adaptor sold separately. The remote meter can be connected to a PC or device using an RS485 to USB cable sold separately.

If you already have one of our compatible high frequency inverters you can easily add this remote meter to your inverter - just plug the cable supplied with the meter into the RJ45 socket of the inverter.

Please note this product is suitable for panel or recess mount.

Click on the Details and Specifications tab for more information about this product.

Specifications:

• Suitable for IPT series high frequency inverters
• Self-consumption: 14-23mA (depending on backlight settings)
• Operating temperature: -20C to +60C
• Communication cable: RJ45 (8pin) 5 metres included
• Wall mounting frame with mounting holes included
• Dimensions: 100 x 100 x 19.4 mm
• Recess size (recommended): 78.5 x 53.5mm
• Weight: 65 g

The product is covered by a 1 year manufacturer warranty. For more information please refer to our Terms and Conditions.

Please note that this circuit breaker is intended for panel or recess mounting.

The unit comes with a detailed user manual which explains connection and operations.

If you need help with installation or have any technical questions we can provide FREE support - please contact us by email or phone (see Contact Us page for more information).

You can download the following documents for this product:

User manual for MT91 remote meter for IPT series inverters
