This high quality, brand new remote display / monitor can be used simultaneously with Photonic Universe IPT series high ferquency inverters and high efficiency MPPT charge controllers (TR/PTR/XTR series). It's ideal to monitor the status of a combiend AC/DC system with compatible equipment to provide operational and real-time alerts and information. It also allows the control (on/off) of both the AC and DC outputs with a single one-push button. This unit can display various parameters such as PV information (voltage, current, power, total PV generated power); battery (voltage, current, capacity, temperature); DC load (voltage, current, load power, total DC load usage); and AC load (voltage, current, power, AC load usage, AC load frequency).

By adding this remote meter to your IPT series inverter and compatible MPPT solar charge controller, you will unlock a multi functional display that provides information on your AC and DC power system for ease of monitoring and troubleshooting comfotrably all in one panel.

Additional Features:

Remotely control of the load output (on/off) for the inverter and solar charge controller by pressing a single button. Ideal for conveniently disconnecting the load outputs to reduce battery discharge when no load is required. Optional connection of a dry-contact between the MT80 and inverter will unlock direct control over the inverter on/off state to reduce the inverter energy losses even further to improve system efficiency and power management.

This remote meter also has self-diagnostic capability, and will highlight any system errors using advanced fault-targeting technology. Fitted with a series of clear fault codes the display will assist with diagnosing an issue should it occur with either the DC or AC side of the system for convenient troubleshooting.

Advanced remote monitoring capability and access parameter settings

The remote meter can be further extended with connectivity capability to a wide range of options. Access parameter settings and real-time monitoring remotely via connection to a Wi-Fi module, Bluetooth module, RJ45 to USB cable, or 4G dongle.

Compatibility:

This remote meter can be used with any of our high frequency IPT series inverters, e.g.:

- IPT-1000
- IPT-2000
- IPT-3000
- TRxxxxBN, TRxxxxAN, PTR and XTR series MPPT solar charge controllers

If you already have these compatible high frequency inverters and solar charge controllers, you can easily add this remote meter to your system - just plug the cable supplied with the MT80 meter into the RJ45 socket of the inverter and remote meter respectively.

Click on the Details and Specifications tab for more information about this product.

Specifications:

• Suitable for IPT series high frequency inverters
• Self-consumption: 16-27mA (depending on backlight settings)
• Operating temperature: -20C to +65C
• Communication cable: 2 x RJ45 (8pin) communication cables; 1 x dry contact connection cable
• Wall mounting frame with mounting holes included
• Dimensions (without frame): 193 x 95 x 23 mm
• Dimensions (with frame): 193 x 95 x 48 mm
• Weight: 290 g

The product is covered by a 1 year manufacturer warranty. For more information please refer to our Terms and Conditions.

The unit comes with a detailed user manual which explains connection and operations.

If you need help with installation or have any technical questions we can provide FREE support - please contact us by email or phone (see Contact Us page for more information).

You can download the following documents for this product:

User manual for MT80 remote meter for IPT series inverters and TR/PTR/XTR series MPPT solar charge controllers
